Product Features
1” (25,4 mm) aluminum voice coil
Power handling: 15 WAES
High sensitivity: 105 dB (1W / 1m)
Extended frequency range: 3 - 20 kHz
Narrow directivity: 40º conical
Aluminum diaphragm
Designed for outdoor applications
Designed for using in multi-element loudspeaker systems in sound reinforcement applications
Technical Specifications
Rated impedance 8 Ω
Minimum impedance 6,4 Ω
D.C. resistance 5,4 Ω
Power capacity 15 WAES above 5 kHz
Program power 30 W above 5 kHz
Sensitivity 105 dB 1W / 1m @ ZN
Frequency range 3 - 20 kHz
Recommended crossover 6 kHz or higher (12 dB/oct min.)
Dispersion H x V 40º conical
Voice coil diameter 25,4 mm 1 in
Flux density 1,45 T
Bl factor 4 N/A
