TECHNICAL SPECIFICATIONS
Nominal diameter: 200 mm. / 8 inch
Rated impedance: 8 ohms
Minimum impedance: 6.9 ohms
Power capacity *: 250 Watts AES
Program power: 500 Watts
Sensitivity: 98 dB 2.83v @ 1m @ 2p
Frequency range: 150 - 7000 Hz
Voice coil diameter: 51.7 mm. 2 in
Magnetic assembly weight: 2.8 kg. 6.17 lb.
BL factor: 9.8 N / A
Moving mass: 0.017 kg
Voice coil length: 9 mm
Air gap height: 7 mm
UPC: 613815563686
MOUNTING INFORMATION
Overall diameter: 212 mm. 8.35 in.
Baffle cutout diameter: 198 mm. 7.8 in.
Front mount: 181 mm. 7.12 in.
Rear mount: 183 mm. 7.2 in.
Depth: 94 mm. 3.7 in.
Volume displaced by driver: 1.5 l 0.056 ft.3
