Product Specifications
Impedance 4 ohms
AES Power Rating 25 Watts
Program Power 50 Watts
Sensitivity (1W/1m) 107dB 1w @ 1m
Frequency Response 2.5kHz - 22kHz
Recommended Crossover 3.7 kHz or higher
Voice Coil Diameter 1.02" / 25.8mm
Mounting Information
Overall Diameter 2.36" / 60mm
Overall Depth 2.68" / 68mm
Baffle Cutout Dimensions 1.69" / 43mm
Bolt Circle Diameter 2.03" / 51.5mm
Materials
Diaphragm Aluminum
Front Cover Aluminum
Magnet Neodymium
