Nominal Diameter 254mm/10in
Nominal Power Rating 250W
Continuous Power Rating 500W
Sensitivity 96dB
Rated Impedance 8Ω
Frequency Range 55Hz-3500Hz
Voice coil diameter (mm) 64mm
Voice coil diameter (in) 2.5in
Chassis Type Cast aluminum
Magnet Type Neodymium
Voice coil material Copper clad aluminum
Former Material Glass fibre
Cone material Kevlar loaded paper
Surround Material Cloth sealed
Suspension Single
Xmax 4mm/0.16in
Gap Depth 8mm/0.32in
Voice coil winding width 16mm/0.63in
Mounting slot dimensions 7.5mm x 6.5mm/0.3in x 0.26in Ø
Mounting slot PCD 244mm-247mm/9.6in-9.7in
Number of mounting slots 4
Overall Depth 113mm/4.45in
Overall Diameter (mm) 260mm
Overall Diameter (in) 10.24in
Cut-out diameter 232mm/9.13in
Unit Weight 2.2kg/4.89lb
