TECHNICAL SPECS (2 Ohms):
Number of Channels: 4
RMS Power in 2 Ohms 12.6V: 4 x 225W RMS (STEREO)
RMS Power in 4 Ohms 12.6V: 4 x 140W RMS (STEREO)
RMS Power in 2 Ohms 13.8V: 4 x 260W RMS (STEREO)
RMS Power in 4 Ohms 13.8V: 4 x 165W RMS (STEREO)
Power @ 12.6V Bridge 4 Ohms: 2 x 450W RMS
Power @ 13.8V Bridge 4 Ohms: 2 x 520W RMS
Power Supply: 9 ~ 15V
Frequency Response: 10Hz ~ 26KHz
Low Pass Crossover: 90 Hz
High Pass Crossover: 90 Hz
Bass Boost (Low Pass): +12 dB
Minimum output impedance: 2 Ohm (STEREO) / 4 Ohms (BRIDGE)
Musical Consumption: 44A
BASS Consumption: 88A
Dimensions (H x W x L): 2.5" x 8.1" x 8.1"
Weight: 3.7 lb
Number of Channels: 4
RMS Power in 2 Ohms 12.6V: 4 x 225W RMS (STEREO)
RMS Power in 4 Ohms 12.6V: 4 x 140W RMS (STEREO)
RMS Power in 2 Ohms 13.8V: 4 x 260W RMS (STEREO)
RMS Power in 4 Ohms 13.8V: 4 x 165W RMS (STEREO)
Power @ 12.6V Bridge 4 Ohms: 2 x 450W RMS
Power @ 13.8V Bridge 4 Ohms: 2 x 520W RMS
Power Supply: 9 ~ 15V
Frequency Response: 10Hz ~ 26KHz
Low Pass Crossover: 90 Hz
High Pass Crossover: 90 Hz
Bass Boost (Low Pass): +12 dB
Minimum output impedance: 2 Ohm (STEREO) / 4 Ohms (BRIDGE)
Musical Consumption: 44A
BASS Consumption: 88A
Dimensions (H x W x L): 2.5" x 8.1" x 8.1"
Weight: 3.7 lb
